Increase uptime of your process critical equipment.


Value Section 1.png
Transponder Highlight.png

Transponder

Communicates with sensors and securely transfers data to the cloud.

Communication

  • 16-bit MCU

  • Protocol 802.11 b/g/n WiFi 2.4 GHz

  • WPA2 with AES encryption

  • Bluetooth low energy 2.4 GHz (Customized Protocol)

Physical Dimensions

  • Height: 16” / 40.6 cm

  • Width: 7” / 17.8 cm

  • Depth: 3.75” / 9.5 cm

  • Weight: 3.4 lbs / 1.55 kg

Mechanical Specifications

  • Vibration testing to UN DOT 38.3

  • Ruggedized enclosures

  • Corrosion resistant

  • RoHS compliant

  • Power requirement 24V DC, < 10W


Sensor Highlight.png

Sensors

Tri-axial vibration and temperature sensors.

Sensor Data

  • Tri-axial accelerometer - frequency response up to 8kHz (xy), 5.1kHz (z) - measurement range up to 20 G - 16 bit resolution

  • Temperature sensor - accuracy of +/- 1°C

Physical Dimensions

  • Height: 5” / 12.7 cm

  • Largest diameter: 2” / 5.1 cm

  • Weight: 0.33 lbs / 0.15 kg

Mounting Provisions

  • Magnetic mounts

  • Epoxy or threaded studs

  • ¼-28 UNF tapped hole

Mechanical Specifications

  • Ruggedized enclosures

  • Corrosion resistant

  • Stainless steel base

  • RoHS compliant

  • Temperature operation to -20C to +60C (-4F to +140F)


Software Highlight.png

Cloud-based software program

Delivers actionable data customized to your specifications and tailored alerts via SMS, email or phone.

Dashboard

  • Easy to understand temperature and vibration charts

  • Peak overall velocity graphs for vibration analysis

  • Isolate X, Y, or Z Axis for vibration analysis

  • 8192 samples with each vibration data point

  • Toggle between celsius and Fahrenheit

  • Easy to recognize notification features designed to reduce alert fatigue

  • Variable sampling frequencies of 256 Hz, 512 Hz, 1024 Hz, 2048 Hz, 4096 Hz, and 8192 Hz

Customization

  • Easily map your equipment with your terminology

  • Time domain waveforms available

  • Spectral waveforms available (FFT)

  • Create notification groups and escalation groups (SMS or Email)




Monthly Live Facility & Asset Update With a VERO Vibration Expert Helps With:

Analyzation & Recommendation for all

  • Asset and Sensor Warnings

  • Threshold Settings and Modification

  • Vibration Best Practices




No batteries to replace

Expert vibration analysis

Easy professional installation

Customized scorecard and analytics

Lifetime warranty and automatic upgrades

Subscription pricing = no CapEx



Artboard 281.png

Our Solution Architects visit your site and evaluate your needs.

We’ll design a custom VERO solution for your equipment and facility.

Once approved we’ll plan and schedule installation.
